Specifications
For full specifications, reference the manual.
| Mild steel cut capacity | Dross free Production pierce Maximum cutting capacity |
16 mm (5/8") 32 mm (1-1/4") 38 mm (1-1/2") |
| Stainless steel cut capacity | Production pierce Maximum cutting capacity |
20 mm (3/4") 25 mm(1") |
| Aluminum cut capacity | Production pierce Maximum cutting capacity |
20 mm (3/4") 25 mm (1") |
| Speed (Mild steel) |
Book specification at highest output current | 12 mm (1/2") 2200 mm/m (80 ipm) |
| Cut angle | ISO 9013 range* | 2-4 |
| Weldability | Ready to weld | |
| Process gases by material (Plasma/shield) | Mild steel Stainless steel Aluminum |
02/Air, 02/02, Ar/Air H35/N2, N2/N2, H35-N2/N2, F5/N2, Ar/Air, Ar/N2 H35/N2, Air/Air, H35-N2/N2, Ar/Air, Ar/N2 |
| Process amps | Not all processes available for all materials | 30-130 |
* ISO 9013 is a standard that defines cut quality of thermally cut parts. The lower the range (range 1 is the lowest), the smaller the angle on the cut face. Cut angle in range 4 is better than in range 5.
Consumables
Please contact an authorized Hypertherm distributor to place your consumables order.
HPR cartridge <130
HPR cartridge consumablesNew!
| Mild steel process | Retaining cap | Cartridge | Water tube | Torch body |
|---|---|---|---|---|
| 80 A (standard cutting)* | 420708 | 420803 | 420728 | 420729 |
| 130 A (standard cutting)* | 420708 | 420705 | 420728 | 420729 |
* HPR cartridge require a new torch body, water tube, and retaining cap. The HPR cartridge torch body connects directly to a standard HPRXD receptacle (part number 220705).
HPR cartridge kitsNew!
| Type | Kit p/n | Includes p/n | Description | Quantity |
| Torch starter kit | 528101 | 420729 | Torch body | 1 |
| 420728 | Water tube | 1 | ||
| 420708 | Retaining cap | 1 | ||
| 528107 | Kit: O-ring cartridge torch | 1 | ||
| Cartridge 3-pk kits |
528102 | 420803 | Kit: Cartridge, 80 A | 3 |
| 528103 |
420705 |
Kit: Cartridge, 130 A | 3 | |
| 528105** | 420803, 420705, 420715 | Kit: Cartridge, multi-amps | 3 |
** Note: 528105 cartridge multi-amps kit contains (1) of each amperage (80 A, 130 A, and 260 A).
HPR130XD standard consumables
Mild steel
130 amp consumables - mild steel
| Amperage | Shield cap |
Shield | Nozzle retaining cap |
Nozzle | Swirl ring | Electrode | SilverPlus electrode | Water tube |
|---|---|---|---|---|---|---|---|---|
| 30 A | 220747 | 220194 | 220754 | 220193 | 220180 | 220192 | ______ | 220340 |
| 50 A | 220747 | 220555 | 220754 | 220554 | 220553 | 220552 | ______ | 220340 |
| 80 A | 220747 | 220189 | 220756 | 220188 | 220179 | 220187 | 420566 | 220340 |
| 130 A | 220747 | 220183 | 220756 | 220182 | 220179 | 220181 | 220665 | 220340 |
| 80 A bevel | 220637 | 220742 | 220845 | 220806 | 220179 | 220802 | ______ | 220700 |
| 130 A bevel | 220637 | 220742 | 220740 | 220646 | 220179 | 220649 | ______ | 220700 |
Stainless steel
130 amp consumables - stainless steel
| Amperage | Shield cap |
Shield | Nozzle retaining cap |
Nozzle | Swirl ring | Electrode | SilverPlus | Water tube |
|---|---|---|---|---|---|---|---|---|
| 45 A | 220747 | 220202 | 220755 | 220201 | 220180 | 220308 | 220340 | |
| 60 A HDi | 220747 | 220815 | 220814 | 220847 | 220180 | 220339 | 220340 | |
| 80 A | 220747 | 220338 | 220755 | 220337 | 220179 | 220339 | 220340 | |
| 130 A | 220747 | 220198 | 220755 (H35) 220756 (N2) |
220197 | 220179 | 220307 | 220340 | |
| 130 A bevel | 220637 | 220738 | 220739 | 220656 | 220179 | 220606 | 220571 |
Aluminum
130 amp consumables - aluminum
| Amperage | Shield cap |
Shield | Nozzle retaining cap |
Nozzle | Swirl ring | Electrode | SilverPlus | Water tube |
|---|---|---|---|---|---|---|---|---|
| 45 A | 220747 | 220202 | 220756 | 220201 | 220180 | 220308 | 220340 | |
| 130 A | 220747 | 220198 | 220755 (H35) 220756 (Air) |
220197 | 220179 | 220307 (H35) 220181 (Air) |
220340 |
HPR130XD starter kits
Designed especially for your HPR130XD system, the Hypertherm consumable kit contains all the necessary consumables and accessories you need to get up-and-cutting. Customers can choose either mild or stainless steel/aluminum consumable starter kits.
| Kit type (MS) | HPR130XD mild steel starter kit (130 A and below) |
|---|---|
| Kit part number | 228420 |
| Description | Kit contains all the necessary consumables and accessories for mild steel cutting at 130 A and below |
| Kit type (MS) | HPR130XD mild steel bevel starter kit (130 A and below) |
|---|---|
| Kit part number | 428626 |
| Description | Kit contains all the necessary consumables and accessories for mild steel bevel cutting at 130 A and below |
| Kit type (AL/SS) | HPR130XD aluminum and stainless steel starter kit (130 A and below) |
|---|---|
| Kit part number | 228421 |
| Description | Kit contains all the necessary consumables and accessories for aluminum and stainless steel cutting at 130 A and below |
Preventive maintenance
HPR130XD preventive maintenance kits
Preventive maintenance kits include all necessary parts for your HPR130XD system.
HPR130XD Auto Gas Preventive Maintenance Program Instruction Manual (Revision 1)
PDF (5.75MB)
HPR130XD Manual Gas Preventive Maintenance Program Instruction Manual (Revision 1)
PDF (5.65MB)
Upgrades
SilverPlus electrodes
SilverPlus® electrodes last over two times longer than standard copper electrodes significantly lower operating costs and reducing the number of changeouts.
XPR170 plasma cutting system
The XPR170® mechanized plasma cutting system delivers next generation X-Definition® processes from very thin up to mid-range thicknesses.
